PHB

对流预热设备

Heating area 360 x 277 mm.

The most complete solution to preheating multilayer PBCs.

Improve soldering quality. Work at lower temperatures and in less time.

By using the console you can select 2 independent heating zones and the operation mode: by power or by temperature.

With 3 preset temperature profiles and 20 more

to personalize. Once a profile has been run, you can work without thermocouple.

Control Thermocouple follows a temperature profile precisely and Auxiliary Thermocouple protects PCB

技术参数:

尺寸:426 x 446 x 41 mm

保险丝:15 A T (100V & 120V), 10 A T (230V)

加热面积:180 or 360 x 277 mm (2 zones)

JBC设定的温度曲线:3 profiles ( 2, 3 or 4 steps)

最大功率:1800W / 1800W / 1400W

最大工作时间:600min. or indefinite

包装尺寸:595 x 520 x 180 mm

包装重量:9.20 kg

温度测量:Thermocouple type K

温度范围:50 to 250C (120 to 482F)

用户配置文件:20 (up to 6 steps for each)

电压:120V / 230V / 100V

重量:6.98 kg
